Split Type Four—Axle Grinding and Polishing Machine
Keywords:
Split Type Four—Axle Grinding and Polishing Machine
Category:
- Details
- Characteristics
- Parameters
- Application
-
- Commodity name: Split Type Four—Axle Grinding and Polishing Machine
It provide different polishing and grinding plats with different specs, which could be used in the polishing and grinding of different kinds of optical glasses, quartz, crystals and other fragile flat and sphere surface.
It provide different polishing and grinding plats with different specs, which could be used in the polishing and grinding of different kinds of optical glasses, quartz, crystals and other fragile flat and sphere surface.
1.The machine tool adopts split structure, which is convenient for transportation.
2.The machine tool itself adopts frequency conversion speed regulation, and its spindle and pendulum shaft can be controlled separately.
3.Large torque, no vibration and low noise, can meet the requirements of various optical processes.
4.Provides a variety of specifications polishing and grinding plate, can be used for a variety of optical. glass, quartz, crystal and other brittle materials plane, spherical grinding and polishing. -
1.The machine tool adopts split structure, which is convenient for transportation.
2.The machine tool itself adopts frequency conversion speed regulation, and its spindle and pendulum shaft can be controlled separately.
3.Large torque, no vibration and low noise, can meet the requirements of various optical processes.
4.Provides a variety of specifications polishing and grinding plate, can be used for a variety of optical. glass, quartz, crystal and other brittle materials plane, spherical grinding and polishing. -
Projection Parameters Processing Scope ≤200mm Spindle Parameters 10-140r/ min Pendulum shaft parameters 10-100r/ min Power & Voltage 2.4kW Dimension 1030*910*1100(mm) Weight 260KG Spindle thread M27-3 Beat of Plate ≤0.015mm Maximum Adjustable Range of Pendulum 0-100mm Diameter of Plate ≤250mm Operation Interface PLC+HMI
